GEOMETRIC DIMENSIONING & TOLERANCING (42 HOURS)
| Use Your SkillsFuture Credit Before It Expires! Tap on your $500 SkillsFuture Credit (which expires in December 2025) to offset our course fees! Whether you're upskilling for a career switch or looking to enhance your current expertise, make full use of this credit before it expires and invest in your professional growth today. |
- This module is offered under the Mechatronics specialisation.
Introduction
This course aims to provide students with fundamental knowledge and practical skills on the subject of Geometric Dimensioning and Tolerancing (GD&T). The course is conducted in an interactive way with case studies and hands-on experiments.
GD&T is a graphic language used by mechanical designers, engineers, and quality inspection operators to effectively and accurately communicate with one another through detailed drawings. It defines the geometry of mechanical parts without any ambiguities through symbols for geometric dimensions, tolerances and relative positions among features and datums. With GD&T defined drawings, desired forms and fits can be realised. This ensures the intended function of the parts and assemblies.
Why This Course
GD&T is a powerful communication tool used in the precision engineering industry. These days, more companies are required to generate drawings that are dimensioned and toleranced with GD&T. This course is conducted by instructors with strong industrial experience in using GD&T. It also includes case studies discussions and intensive hands-on sessions to enhance the participants’ GD&T understanding.
Who Should Attend
This course is recommended for
- Mechanical designers and engineers
- Quality manufacturing inspection operators, engineers and managers
- Those interested in understanding and applying engineering drawings
What our trainees say
This was a great course covering the fundamentals and some intermediate/advanced GD&T content. It was supported by case studies and hands-on lab sessions to further deepen students' understanding.
Mr Jovan Ong,
Participant from Sep 2024 intake
The course has provided me with good fundamental and practical understanding of GD&T. The theory of GD&T was meticulously taught which translated to clear and informative practical sessions.
Mr Lionel Lai,
Participant from Sep 2024 intake
Both instructors are very professional and knowledgeable. The way they explain complex topics is clear and concise.
Mr Shawn Ng,
Participant from Sep 2024 intake
I feel that this course has benefitted me in ways that I didn't think of. The execution of the lessons was done amazingly and I'm able to apply my learnings in my daily job.
Mr Mohamed Affan,
Participant from Nov 2023 intake
Overall, I feel the course has been very useful and helpful in many ways. The course definitely relates to my current job and the field where I am working at.
Mr Jeff Ngo,
Participant from Nov 2023 intake
What You Will Learn
What You will Learn
GD&T fundamental concepts and form control
- GD&T symbols, terms and rules
- Datum and datum system
- Form control
GD&T position tolerance control and graphic analysis
- Position tolerance control
- Graphic analysis (paper gage)
Orientation, run-out and profile control
- Orientation, run-out and profile control
Advanced GD&T and Applications
- GD&T advantages over coordinate dimensioning
- Strategy for tolerancing parts
Upon Completion of This Course
Upon Completion of this Course
Electronic Statement of Attainment (SOA) certificates (in OpenCerts Formats) will be issued by SkillsFuture Singapore (SSG) to participants who have attended and attained competency in the Singapore Skills Framework training modules.
Participants must also meet the following criteria to receive their SOAs:
- Achieve at least 75% course attendance;
- Take all assessments; and
- Pass the course.
Find out more about the WSQ SOA certificate.
Note: Trainees will have to bear the full course fee upon failure to meet either one of the criteria.
|
In addition, please note that participants' SOA certificates will display the Skills Standard title, not the course title. For this course, the certificate will indicate the Skills Standard: Analyse the Impact of GD&T on Manufacturing Processes to Select Appropriate Engineering Interventions. |
The name printed on the Statement of Attainment (SOA) issued by SkillsFuture Singapore is the Skills Standard title, such as a Technical Skills and Competency (TSC) title, rather than the course title. This is because the SOA is aligned with the national Skills Framework, ensuring consistent recognition across industries and among employers. While the course title describes the learning experience, the SOA certifies the specific nationally recognised competency attained.
Pre-Requisites, Full and Nett Course Fees
Pre-Requisites
- Applicants should possess a degree in any discipline or a diploma with a minimum of 3 years of related working experience.
- Applicants who do not have the required academic qualifications are still welcome to apply, but shortlisted candidates may be required to attend an interview for special approval.
- Proficiency in written and spoken English.
Full Course Fee
The full course fee for this course is $3,000 before funding and prevailing GST.Nett Course Fee
